AEM's Brute Force Air Intake Systems are tuned and dyno-tested to give your engine more power and acceleration by replacing the restrictive factory air filter, air intake tubing and air box assembly.
The AEM 21-9221DS Brute Force Air Intake System produces horsepower and torque gains by replacing the vehicle's restrictive factory air filter and air intake housing. This air intake system was designed, tuned and dyno-tested to fit specific Dodge Ram 2500/3500 Pickup models. Air enters the system through an extra-large AEM Dryflow synthetic washable air filter for outstanding air flow, filtration and performance. The air filter is located in the original air box space and is protected by a heat shield which is designed to reduce intake air temperature and increase horsepower. The intake tubing is an aerodynamically engineered and highly durable polyethylene tube. This air intake system was developed to accommodate the engine's factory emissions control devices including the mass air flow sensor and IAT sensor. The oval cone shaped AEM Dryflow air filter is made from an oil-free, synthetic filter media that can be used for up to 100,000 miles before cleaning is needed (depending on driving conditions). The air intake system is easy to install with commonly available tools.
- Increased Horsepower
- Tuned And DynoTested To Improve Acceleration And Engine Sound
- Low Restriction Aluminum Tubing
- Easy To Install Using Commonly Available Tools
- Air Filter Lasts Up To 100 000 Miles BF Cleaning Is Required
- Washable And Reusable Oil Free Filter Media
- AEM Lifetime Limited Warranty
- Limited Lifetime Warranty
Information:
Increased Horsepower; Tuned And DynoTested To Improve Acceleration And Engine Sound; Free Flowing High Density Tube; Easy To Install Using Commonly Available Tools; Air Filter Lasts Up To 100 000 Miles BF Cleaning Is Required; Washable And Reusable Oil Free Filter Media; Will Not Void Vehicles Warranty; Limited Lifetime Warranty
Application Summary:
| Year |
Make/Model |
| 2007-2009 |
Dodge Ram 2500 |
| 2007-2009 |
Dodge Ram 3500 |
| Attributes |
| ASIN |
B001DX9I0Q |
| Air Box Included |
No |
| Air Filter Color |
Red |
| Air Filter Element Washable |
Yes |
| Air Filter Height |
9.313 in (237 mm) |
| Air Filter Material |
Non-woven Synthetic |
| Air Filter Oulet Length |
5.000 in. (127mm) |
| Air Filter Oulet Width |
5.000 in. (127mm) |
| Air Filter Outlet Length |
5 in (127 mm) |
| Air Filter Outlet Shape |
Round |
| Air Filter Outlet Width |
5 in (127 mm) |
| Air Filter Washable |
Yes |
| Alternate Part Number |
AEM-21-9221DS |
| CARB EO Number |
D-670-2 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Clamp Color |
Natural |
| Clamp Color/Finish |
Natural |
| Clamp Material |
Steel |
| Clamp Quantity |
1 |
| Clamp Style |
Regular |
| Clamps Included |
1 |
| Color |
Black |
| Country of Origin (Primary) |
US |
| Coupler Color |
Not Applicable |
| Coupler Color/Finish |
Not Applicable |
| Couplers Included |
None |
| Emission Code |
Legal US |
| Filter Color |
Red |
| Filter Material |
Non-woven Synthetic |
| GTIN |
00840879017736 |
| Harmonized Tariff Code (Schedule B) |
8421310000 |
| Hazardous Material Code |
N |
| Intake Pipe Color |
Black |
| Intake Pipe Color / Finish |
Black |
| Intake Pipe Inlet Shape |
Round |
| Intake Pipe Material |
High-Density Cross-Linked Polyethylene |
| Intake Pipe Outlet Shape |
Round |
| Intake Pipe Ports |
All intake tube ports needed for the specified applications are included |
| Item Weight |
13.000 lbs. (5.9 kg) |
| Life Cycle Status Code |
Available to Order |
| Mass Air Flow Sensor Adapter Included |
Yes |
| Mass Air Flow Sensor Included |
Mass Air Flow Sensor Adapter Included When Required |
| Mounting Hardware Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| Oil Included |
No, No Filter Oil Required |
| Package Material |
Paperboard |
| Package Type |
Box |
| Product Box Height |
14.940 in. (379mm) |
| Product Box Length |
22.200 in. (564mm) |
| Product Box Width |
14.500 in. (368mm) |
| Product Style |
AEM Brute Force HD Intake |
| Replacement Filter |
21-2279DK |
| SDR Required Flag |
N |
| Standard Pack |
1 |
| Street Legal |
Yes |
| Street Legal In All US States |
Legal for use in all 50 states. |
| System Type |
Cold Air Induction |
| TUV Approved (Europe) |
No |
| Warranty |
Limited Lifetime |
| Weight |
13 lb (5.9 kg) |
